Our Facilites & Equipment

CNC Equipment:

• Supermax YCM-40, 3 axis CNC milling machine with Dynapath Delta 10 controller
  Travels: X-28.0", Y-14.0", Z-5.25" with 15" knee travel. 3HP, 4,600 rpm spindle
• (2) Hardinge Cobra 42 Turning Center with GE/Fanuc 21-T controller
  Travels: X-7.75", Z-14.0", 1-5/8" bar capacity, 10HP, 5,000 rpm spindle
• Fadal VMC 3016 Vertical Machining Center with Fadal CNC88HT controller
  Travels: X-30.0", Y-16.0", Z-20.0", 15HP, 10,000 rpm spindle with box ways
• Supermax Max-4 Rebel Vertical Machining Center with Fanuc OMC controller
  Travels: X-43.3", Y-23.3", Z-24.4", 20HP, 8,000 rpm spindle with box ways
• Upgrade Technology GT-27 gang tool lathe with Fanuc GE 21i T controller
  5C collet with 1-1/16" thru spindle bore, 5HP, 5,000 rpm spindle
• (2) Supermax Max-1 Rebel Vertical Machining Center with Fanuc OMC controller
  Travels: X-25.8", Y-16.8", Z-24.0", 15HP, 8,000 rpm spindle with box ways

Manual Equipment:

• Bridgeport Series 1 2HP, vertical milling machine, 9" x 42" table, power feed
  Newal 2-axis DRO
• Victor 1640B engine lathe, 16" x 40" with collet closer and 10" chuck for 16"
  swing capacity. Sony 2-axis DRO, .0001" increments. inch/mm
• Hardinge HLVM toolroom lathe with 5C collet closer and 5" chucks for 8"
  swing capacity. Sony 2-axis DRO, .0001" increments inch/mm

Support Equipment:

• Baldor 8" dual wheel pedestal carbide tool grinder, 1/2HP
• Dayton 7" dual whell pedestal tool grinder
• Rockwell 28-200 14" vertical band saw
• Chicago 1014 14" abrasive disc cut-off saw
• Dayton 1" belt sander
• Central Machinery 1600 16-speed floor drill press, 3/4HP
• Trinco Cyclo - Blast bead blaster with built in tumbling feature
• Ultrasonic cleaner/degreasers, heated and non-heated
• Mr. Burr Vibratory Tumbler, 3 cu ft.
• Kalamazoo Horizontal Band Saw Model AW9HSA

Inspection Equipment:

• ISO 9001 Standards
• Standridge inspection grade surface plate, 24" x 36"
• Mojave tool room grade surface plate, 12" x 18"
• Digi-dial height gauge, 0" - 18" with .0001" test indicator
• set of gauge blocks, .050" - 4.000"
• set of plug gauges, .011" - 1.000"
• set of depth micrometers, 0" - 12"
• set of telescoping gauges, .500" - 6.000"
• set of inside micrometers, 0" - 6.000"
• set of outside micrometers, 0" - 6.000"
• set of dial depth gauges, 0" - 10.000"
• Dial bore guage, .700" - 1.500"
• Browne & Sharpe dial calipers, 0" - 6.000"
• Mititoyo dial caliper, 0" - 12.000"
• Mititoyo Digimatic caliper, 0" - 6.000"
• Mititoyo Digimatic micrometers, 0" - 1.000", .00005" increments
• Browne & Sharpe dial & test indicators, .0001", .0005", .001", .500", 1.000", 2.000"
• Mititoyo Digi-dial height gauge, 0" - 12" with .0001 test indicator
• Mititoyo thread micrometer, 0" - 1.000", .0001 increments
• Assorted thread plug gauges
• Leica M85 Electronic Stereomicroscope
